Description

Power supply Spec.:
Input Voltage range: AC90V-AC290V
Output voltage: DC24V
Output current: 1.5A
Max Power: 40W
Power supply efficiency: >90%
PFC: >0.95
THD: ≤6%
Surge: 4KV

Motor driver spec.:
Control way: Sin wave control, FOC
Hall sensor: Sensorless
RPM: 0-600 with 48-56 blade
Speed control: RF / VSP
Speed feedback: Yes
Forward/Reverse function: Yes

Protection function:
Current limit, Over current, Over voltage
Phase loss, Anti-lock

Material : FR-4 1 OZ ; thickness 1.6mm;
